Phanuphong Steel is a reliable manufacturer and supplier of QUARD 450 Sheet and Plates in Bangkok, Thailand, offering superior wear-resistant steel products for diverse sectors. Our plates of QUARD 450 ensure superior hardness, strength, and impact resistance that make them apt for mining, construction, quarrying, and heavy machinery equipment. Dedicated to innovation and superiority, we confirm our products reach the highest quality standards of industries, ensuring strength and durability. Select Phanuphong Steel for trusted, high-quality steel solutions customized to your requirements.
QUARD 500 sheets and plates are made from a blend of alloy steel, featuring carbon, manganese, silicon, chromium, nickel, and molybdenum, all of which enhance their strength and toughness. With a hardness rating of around 500 HBW, these plates boast impressive wear resistance and remarkable impact strength. They also demonstrate high yield and tensile strength, ensuring they can withstand heavy loads and harsh conditions. The fine-grained microstructure contributes to their toughness, while precise quenching and tempering processes ensure exceptional hardness and consistent mechanical properties, making QUARD 500 the go-to choice for heavy-duty, abrasion-resistant applications across various industries.
Item:Â Abrasion Resistant Plate
Thickness :Â 4MM & Above
Length :Â Up to 12000 mm
Width :Â 1500 – 3100 mm
Production :Â Hot-Rolled (HR) / Cold-Rolled (CR)
Applications :Â concrete industry, metallurgy, fan industry, coal industry, mining machinery, construction machinery,etc.
Heat Treatment:Â N, Q+T
Material :Â QUARD 500 Plates, QUARD 500 Abrasion Resistant Steel Plates, QUARD 500 Wear Resistant Plates
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | B |
| Quard 500 | 0,28-0,30 | 0,80 | 1,60 | 0,025 | 0,01 | 1,00 | 1,00 | 0,50 | 0,005 |
| Grade | V-notch impact test (longitudinal at –40°C) | Yield strength (MPa) | Tensile strength Transverse testing (MPa) | Elongation A5 (%) |
| Quard 500 | 30 J | 1,500 | 1,700 | 8 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
