Phanuphong Steel and Plates, a top-notch manufacturer and supplier based in Bangkok, Thailand, proudly presents its high-quality ABREX 400 Plates, specifically crafted to meet the rigorous demands of wear-resistant applications. Renowned for their remarkable hardness and durability, these plates are a go-to choice in industries where strength and reliability are non-negotiable. With a strong commitment to quality assurance and compliance with international standards, Phanuphong Steel guarantees that ABREX 400 Plates deliver exceptional performance, extended service life, and cost-effectiveness. Their impressive strength makes them perfect for heavy-duty tasks across construction, mining, and material handling sectors.
The ABREX 400 Plates are primarily made up of carbon, manganese, chromium, nickel, and molybdenum, which significantly boost their wear resistance and toughness. With a nominal hardness of 400 BHN, they provide an excellent strength-to-weight ratio and outstanding abrasion resistance. These plates also showcase high impact strength, superior weldability, and good machinability, making them easy to fabricate without sacrificing mechanical integrity. Their well-balanced composition and mechanical properties ensure they remain durable and perform reliably, even in the toughest conditions.
| Item | Abrasion Resistant Plate |
|---|---|
| Material | ABREX 400, SUMIHARD, BRINAR, DUROSTAT, DILLIDUR, JFE EVERHARD. |
| Thickness | 3 – 200mm |
| Width | 500 – 3000mm |
| Length | 1000 – 12000mm |
| Heat Treatment | N, Q+T |
| Surface Paint | EP, PE, HDP, SMP, PVDF |
| Plate | C | Si | Mn | P | S | Cr | Ni | Mo | B | CEV | CET |
| 3- 6 | 0.15 | 0.70 | 1.60 | 0.025 | 0.01 | 0.50 | 0.25 | 0.25 | 0.004 | 0.41 | 0.28 |
| 3-（8） | 0.15 | 0.70 | 1.60 | 0.025 | 0.01 | 0.30 | 0.25 | 0.25 | 0.004 | 0.33 | 0.23 |
| 8 – 20 | 0.15 | 0.70 | 1.60 | 0.025 | 0.01 | 0.50 | 0.25 | 0.25 | 0.004 | 0.37 | 0.27 |
| （20）-32 | 0.18 | 0.70 | 1.60 | 0.025 | 0.01 | 1.00 | 0.25 | 0.25 | 0.004 | 0.48 | 0.29 |
| （32）-45 | 0.22 | 0.70 | 1.60 | 0.025 | 0.01 | 1.40 | 0.50 | 0.60 | 0.004 | 0.57 | 0.31 |
| （45）-51 | 0.22 | 0.70 | 1.60 | 0.025 | 0.01 | 1.40 | 0.50 | 0.60 | 0.004 | 0.57 | 0.38 |
| （51）-80 | 0.27 | 0.70 | 1.60 | 0.025 | 0.01 | 1.40 | 1.00 | 0.60 | 0.004 | 0.65 | 0.41 |
| （80）-130 | 0.32 | 0.70 | 1.60 | 0.025 | 0.01 | 1.40 | 1.50 | 0.60 | 0.004 | 0.73 | 0.48 |
| Grade | Mechanical Property | Charpy V Impact Test | |||
| ABREX 400 | Yield | Tensile | Elongation | Degree | longitudinal |
| Min Mpa | Mpa | Min % | -40 | J | |
| 1000 | 1250 | 10 | 45 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Phanuphong Steel is a trusted manufacturer and supplier of high-quality ABREX 400 Plates in Bangkok, Thailand. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your ABREX 400 Plates needs!
You’ll find ABREX 400 Plates widely utilized in industries that demand wear and abrasion resistance. They’re commonly found in mining equipment, dump truck liners, crushers, hoppers, and chutes, where materials face constant impact and sliding. Construction and earthmoving machinery also rely on these plates for buckets, blades, and conveyors, thanks to their impressive hardness and toughness. Moreover, the steel, cement, and power industries have adopted ABREX 400 Plates to enhance operational efficiency by minimizing downtime and maintenance costs, ensuring they deliver long-lasting performance and reliability in heavy-duty operations.
