Phanuphong Steel and Plates stands out as a top-notch manufacturer and supplier of premium Carbon Steel Forged Fittings, proudly based in Bangkok, Thailand. Known for their precision-engineered products, they cater to a diverse array of industries, including oil & gas, petrochemical, power generation, and heavy engineering. Their forged fittings comply with both international and industrial standards like ASTM A105 and ASME B16.11. With a commitment to strength, durability, and resistance to high pressure and temperature, Phanuphong Steel guarantees reliable performance in demanding applications, earning a solid reputation for carbon steel solutions across Thailand and Southeast Asia.
When it comes to Carbon Steel Forged Fittings, they are usually crafted from ASTM A105 material, which includes carbon (up to 0.35%), manganese (0.60–1.05%), phosphorus (≤0.035%), sulfur (≤0.040%), and some trace elements like silicon. These fittings boast impressive mechanical properties, featuring a minimum tensile strength of 485 MPa, a yield strength of at least 250 MPa, and a minimum elongation of 22%. They are specifically designed to endure high-pressure and high-temperature conditions, providing exceptional toughness and ductility. The forging process improves grain flow, mechanical strength, and fatigue resistance, making them ideal for critical and high-stress piping systems.
| Forged Fittings Specifications | ASTM A105/ ASME SA105 |
|---|---|
| Carbon Steel Forged Fittings size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Carbon Steel Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Carbon Steel Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM A105 Carbon Steel Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Carbon Steel Forged Fittings Thread | NPT, BSPT, BSPP |
| Carbon Steel Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Carbon Forged Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| ASTM A105 / A105M | Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Carbon Steel Forged Fittings |
| BS21 | Threading. |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| ANSI B16.11 | Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings |
| ANSI/ASME B1.20.1 | Pipe threads, general purpose (inch). |
| ISO 4144 | Carbon Steel fittings threaded to ISO 7-1. |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Standard Code | Standard Name |
| ANSI ASME SA-105 | Forged fittings |
| ANSI ASME B16.11 | Socket-welding and Threaded forged fittings |
| MSS SP-79 | Socket-welding reducing Inserts |
| MSS SP-83 | Class 3000 steel socket-welding and threaded unions |
| MSS SP-95 | Swaged nipples and round plugs |
| MSS SP-97 | SW,TH and BW ends for integrally reinforced forged branch outlet |
Carbon Steel Forged Fittings find extensive use in high-pressure piping systems, thanks to their remarkable strength and leak-proof capabilities. You’ll often see them in applications like oil & gas transmission lines, petrochemical facilities, power plants, refineries, marine systems, and hydraulic pipelines. These fittings—such as elbows, tees, couplings, and unions—play a vital role in connecting, redirecting, or terminating pipe flow in both above-ground and underground setups. Their ability to handle high-pressure situations makes them indispensable in various industrial applications.
Phanuphong Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Bangkok, Thailand.
