Phanuphong Steel and Plates, a top-notch manufacturer and supplier based in Bangkok, Thailand, specializes in high-quality DILLIDUR 450V Sheets and Plates that are built for exceptional wear resistance and durability. These plates are renowned for their toughness and reliability, thriving even in the harshest conditions, and are crafted to meet international standards. With impressive hardness and impact strength, DILLIDUR 450V is a go-to choice in industries that demand long-lasting performance. Phanuphong Steel and Plates guarantees precise dimensions, consistent quality, and prompt delivery, making them a reliable partner for DILLIDUR 450V Sheets and Plates across sectors like construction, mining, and heavy engineering.
DILLIDUR 450V Sheets and Plates are made from low-alloy, high-strength steels, featuring essential elements such as carbon, manganese, chromium, nickel, and molybdenum. This unique blend strikes a perfect balance between hardness, toughness, and wear resistance. On the mechanical side, DILLIDUR 450V boasts a nominal hardness of 450 HBW, outstanding tensile strength, and impressive impact toughness, even in colder temperatures. It also excels in resisting abrasion and mechanical wear. With excellent weldability and machinability, these plates are designed to deliver reliability and durability in challenging environments where high-strength, wear-resistant materials are crucial.
Item: Dillidur 450V
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| C | Si | Mn | P | S | Mo | Ni | Cu | Cr | V | Nb | B |
| ≤ 0.25 | ≤ 0.70 | ≤ 1.60 | ≤ 0.025 | ≤ 0.010 | ≤ 0.50 | ≤ 0.80 | ≤ 0.30 | ≤ 1.50 | ≤ 0.08 | ≤ 0.05 | ≤ 0.005 |
| Grade | Mechanical Property | Charpy V Impact Test | |||
| DILIDUR 450V | Yield | Tensile | Elongation | Degree | longitudinal |
| Min Mpa | Mpa | Min % | -20 | J | |
| 950 | 1400 | 11 | 35 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | Â |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
