Phanuphong Steel and Plates, a top-notch manufacturer and supplier based in Bangkok, Thailand, is all about delivering high-quality ARCELOR 500 Sheets and Plates. These products are specifically designed for high-performance and abrasion-resistant applications. With a reputation for cutting-edge manufacturing techniques and rigorous quality control, Phanuphong Steel guarantees that every sheet and plate offers outstanding hardness, strength, and durability, even in the toughest conditions. The ARCELOR 500 Sheets and Plates are built to endure heavy wear, impacts, and the harsh realities of industrial environments, making them perfect for industries like mining, construction, and material handling. Thanks to their technical know-how, prompt delivery, and tailored solutions, Phanuphong Steel has become a go-to provider of premium ARCELOR 500 steel products, not just in Thailand, but beyond.
These ARCELOR 500 Sheets and Plates are crafted from high-strength alloy steel, featuring a meticulously controlled mix of carbon, manganese, and micro-alloying elements that boost hardness, wear resistance, and overall mechanical performance. They boast a Brinell hardness of around 500 HB, impressive tensile strength, and remarkable toughness, ensuring they stand up to extreme abrasion and impact. The careful balance of chemical composition and heat treatment processes guarantees consistent mechanical properties, weldability, and machinability. These sheets and plates are perfect for industrial applications that demand long-lasting performance, strength, and dependable wear resistance in tough environments.
Item: ARCELOR 500
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| Plate Thickness MM | %C Max | %Mn Max | %P Max | %S Max | %SI Max | %Cr Max | %Ni Max | %Mo Max | B Max | CE Max | PCM Max |
| 6.0 – 20.0 | 0.60 | 0.41 | |||||||||
| 21.0 – 40.0 | 0.30 | 1.60 | 0.025 | 0.010 | 0.70 | 1.50 | 1.50 | 0.70 | 0.040 | 0.65 | 0.43 |
| 41.0 – 50.0 | 0.74 | 0.48 |
| Â | Hardness HBW | Typical yield strength MPa, |
| mm | (min – max 1) | not guaranteed |
| 4 – 32 | 470 – 530 | 1250 |
| (32) – 103 | 450 – 540 | 1250 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | Â |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
Phanuphong Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Bangkok, Thailand.
