Phanuphong Steel and Plates, a reputable manufacturer and supplier based in Bangkok, Thailand, is dedicated to providing top-notch EN10305-2 / EN10305-3 ERW Tubing for various industrial and engineering needs. Renowned for their precision, strength, and reliability, these electric resistance welded tubes are crafted to adhere to international quality standards. With their smooth finishes, precise dimensions, and outstanding mechanical performance, Phanuphong Steel and Plates guarantees that their tubing meets the rigorous demands of sectors like automotive, construction, hydraulic, and mechanical systems. Their unwavering commitment to quality, prompt delivery, and customer satisfaction has established them as a go-to supplier for high-performance EN10305-2 / EN10305-3 ERW Tubing across different industries.
The EN10305-2 / EN10305-3 ERW Tubing is made from non-alloy or low-alloy steels that include carbon, manganese, silicon, and trace elements like sulfur and phosphorus. EN10305-2 focuses on welded precision tubes with enhanced dimensional tolerance, while EN10305-3 is tailored for welded circular tubes used in mechanical and general engineering applications. These tubes boast impressive tensile strength, impact resistance, and good elongation properties. They offer consistent hardness, excellent machinability, and resistance to internal pressure. Their blend of strength, precision, and weldability makes them ideal for structural, hydraulic, and automotive engineering systems.
| Steel Name | Steel Number | C max, % max. | Si max, % max. | Mn max, % max. | P max, % max. | S max, % max. |
| E155 | 1.0033 | 0,11 | 0.35 | 0.70 | 0.025 | 0.025 |
| E195 | 1.0034 | 0,15 | 0.35 | 0.70 | 0.025 | 0.025 |
| E235 | 1.0308 | 0,17 | 0.35 | 1.20 | 0.025 | 0.025 |
| E275 | 1.0225 | 0,21 | 0.35 | 1.40 | 0.025 | 0.025 |
| E355 | 1.0580 | 0,22 | 0.55 | 1.60 | 0.025 | 0.025 |
| Steel Name | Â Â Steel Grade | Cold Drawn /Â Hard | Cold Drawn /Â Soft | Â Â Cold Drawn & stress relieved | Â Â Annealed | Â Â Normalised | |||||||
| Rm, Mpa (N/mm2) |
A, % |
Rm, Mpa (N/mm2) |
A, % |
Rm, Mpa (N/mm2) | ReH, MPa (N/mm2) |
A, % |
Rm, Mpa (N/mm2) | A, % | Rm, Mpa (N/mm2) | ReH, MPa (N/mm2) |
A, % |
||
|
E155 |
1.0033 |
400 |
6 |
350 |
10 |
350 |
245 |
18 |
260 |
28 |
270 – 410 |
155 |
28 |
|
E195 |
1.0034 |
420 |
6 |
370 |
10 |
370 |
260 |
18 |
290 |
28 | 300 – 440 |
195 |
28 |
|
E235 |
1.0308 |
490 |
6 |
440 |
10 |
440 |
325 |
14 |
315 |
25 | 340 – 480 |
235 |
25 |
|
E275 |
1.0225 |
560 |
5 |
510 |
8 |
510 |
375 |
12 |
390 |
21 |
410 – 550 |
275 |
21 |
|
E355 |
1.0580 |
640 |
4 |
590 |
6 |
590 |
435 |
10 |
450 |
22 | 490 – 630 |
355 |
22 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Phanuphong Steel is a leading manufacturer and distributor of high-quality EN10305-2 / EN10305-3 ERW Tubing in Bangkok, Thailand. We provide premium steel materials and a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to fast delivery and exceptional customer service, we source top-grade raw materials to ensure superior precision, strength, and durability for demanding industrial applications. Contact us today for all your EN10305-2 / EN10305-3 ERW Tubing needs!
|
Hot rolled |
Outside Diameter, mm |
Tolerance, mm |
|
OD≤101.6 |
+0.4/-0.8 |
|
|
101.6＜OD≤177.8 |
+0.4/-1.2 |
|
|
Cold Drawn |
Outside Diameter, mm |
Tolerance, mm |
|
OD＜25.4 |
±0.10 |
|
|
25.4≤OD≤38.1 |
±0.15 |
|
|
38.1＜OD＜50.8 |
±0.20 |
|
|
50.8≤OD＜63.5 |
±0.25 |
|
|
63.5≤OD＜76.2 |
±0.30 |
|
|
76.2≤OD≤101.6 |
±0.38 |
|
|
101.6＜OD≤177.8 |
+0.38/-0.64 |
|
|
Hot rolled
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤101.6, WT≤2.4 |
+40/-0 |
|
|
OD≤101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD≤101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD≤101.6, WT>4.6 |
+28/-0 |
|
|
OD>101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD>101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD>101.6, WT>4.6 |
+28/-0 |
|
|
Cold Drawn
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤38.1 |
+20/-0 |
|
|
OD>38.1 |
+22/-0 |
EN10305-2 / EN10305-3 ERW Tubing is widely utilized across various industries. In the automotive field, they are commonly found in steering columns, shock absorbers, seat structures, and drive shafts. Hydraulic and pneumatic systems rely on these tubes for pressure lines, cylinders, and fluid power systems due to their dependable performance under stress. In construction and infrastructure projects, they are essential for frameworks, scaffolding, and structural supports. In general engineering, they play a role in machinery parts, furniture manufacturing, and agricultural equipment. Their precision and durability make them a preferred choice in many applications.
