Phanuphong Steel and Plates, a top-notch manufacturer and supplier based in Bangkok, Thailand, specializes in high-quality **Carbon Steel A192 Tubing** tailored for demanding industrial and mechanical applications. Known for its precision, durability, and adherence to international standards, Phanuphong Steel guarantees that each piece of tubing performs reliably even under high pressure and tough conditions. Crafted with cutting-edge production methods and rigorous quality checks, A192 tubing is perfect for mechanical, structural, and engineering projects that demand toughness, accuracy, and long-lasting reliability. Catering to both local and global markets, the company offers versatile and cost-effective tubing solutions that blend exceptional strength, consistent quality, and outstanding performance across various industrial sectors.
The **Carbon Steel A192 Tubing** is mainly made from low-alloy carbon steel, featuring controlled amounts of manganese, phosphorus, and sulfur, which provide an ideal mix of strength, ductility, and toughness. In terms of mechanics, it boasts high tensile strength, good yield strength, impressive hardness, elongation, and impact resistance, making it perfect for heavy-duty, high-pressure applications. Its uniform microstructure, excellent weldability, and durability across different temperatures and pressures make it a great choice for fabrication, mechanical components, and structural assemblies that require reliable performance and a long service life.
| Craft | Cold rolled and Cold drawn |
| Standards | ASTM, ASME and API |
| Length | Min 3 Meters, Max18 Meters, or according to customer’s requirement |
| Thickness | 3-12mm |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Type | Seamless / ERW / Welded / Fabricated |
| Tolerance | Cold drawn pipe: +/-0.1mm
Cold rolled pipe: +/-0.05mm |
| Additional Testing | NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Form | Round, Hydraulic Etc |
| Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| End | Plain End, Beveled End, Treaded |
| Specialized in | Large Diameter ASTM A192 Pipe |
| Size | 1/2” NB to 36” NB |
|
C, % |
Mn, % |
Si, % |
P, % |
S, % |
|
0.06-0.18 |
0.27-0.63 |
0.25 max |
0.035 max |
0.035 max |
|
Tensile Strength , MPa |
Yield Strength , MPa |
Elongation, % |
Hardness, HB, WT≥5.1mm |
Hardness, HRB, WT＜5.1mm |
|
325 min |
180 min |
35 min |
137 max |
77 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Phanuphong Steel is a leading manufacturer and distributor of high-quality Carbon Steel A192 Tubing in Bangkok, Thailand. We offer premium steel materials and a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we source top-grade raw materials to ensure superior strength and durability for demanding industrial applications. Contact us today for all your Carbon Steel A192 Tubing needs!
|
Hot rolled |
Outside Diameter, mm |
Tolerance, mm |
|
OD≤101.6 |
+0.4/-0.8 |
|
|
101.6＜OD≤177.8 |
+0.4/-1.2 |
|
|
Cold Drawn |
Outside Diameter, mm |
Tolerance, mm |
|
OD＜25.4 |
±0.10 |
|
|
25.4≤OD≤38.1 |
±0.15 |
|
|
38.1＜OD＜50.8 |
±0.20 |
|
|
50.8≤OD＜63.5 |
±0.25 |
|
|
63.5≤OD＜76.2 |
±0.30 |
|
|
76.2≤OD≤101.6 |
±0.38 |
|
|
101.6＜OD≤177.8 |
+0.38/-0.64 |
|
|
Hot rolled
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤101.6, WT≤2.4 |
+40/-0 |
|
|
OD≤101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD≤101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD≤101.6, WT>4.6 |
+28/-0 |
|
|
OD>101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD>101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD>101.6, WT>4.6 |
+28/-0 |
|
|
Cold Drawn
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤38.1 |
+20/-0 |
|
|
OD>38.1 |
+22/-0 |
You’ll find the **Carbon Steel A192 Tubing** widely utilized in industries like power generation, oil and gas, chemicals, petrochemicals, and general engineering. It’s suitable for high-pressure boilers, heat exchangers, mechanical components, and piping systems. Thanks to its strength, toughness, and weldability, it’s adaptable for both onshore and offshore applications, as well as industrial fabrication projects that need durable, high-performance steel tubing. Valued for its reliability, performance, and cost-effectiveness, this tubing is a go-to choice for many professionals in the field.
