Phanuphong Steel, a prominent manufacturer and supplier of steel sheets and plates located in Bangkok, Thailand, has built a solid reputation for providing top-notch industrial steel solutions across various sectors. One of their standout products, the SAE 1045 Steel Sheets and Plates, is particularly prized for its impressive balance of strength and toughness. With a strong focus on precision engineering, reliability, and timely delivery, Phanuphong Steel guarantees that its SAE 1045 steel offerings adhere to international standards. These plates find extensive use in engineering, automotive, construction, and manufacturing industries, making them a go-to choice for those seeking durable and cost-effective steel solutions.
SAE 1045 Steel Sheets and Plates are classified as medium carbon steels, containing about 0.43–0.50% carbon and 0.60–0.90% manganese, along with trace amounts of silicon, sulfur, and phosphorus. This specific composition results in a fantastic balance of strength, toughness, and machinability. With a tensile strength ranging from approximately 570–700 MPa and commendable wear resistance, SAE 1045 delivers dependable performance even under stress. Its moderate hardness can be enhanced through heat treatment processes like quenching and tempering, making it suitable for a broad spectrum of industrial applications.
| Specification | ASTM A830 AISI 1045, SAE 1045, |
| Grade | SAE J403 Grade 1045 |
| Condition | hot rolled or normalized |
| Width | Â 200 to 2000mm |
| Thickness | Â 6 to 800mm |
| Length | 2000 to 6000mm |
| Heat treated method | By flame or induction |
| MN | FE | S | C | P |
|---|---|---|---|---|
| 0.60 – 0.90% | 98.51 – 98.98% | ≤ 0.050% | 0.420 – 0.50% | ≤ 0.040% |
| MECHANICAL PROPERTIES | Â | Â |
|---|---|---|
| Â | Metric | Imperial |
| Tensile Strength, Ultimate | 565 MPa | 81,900 PSI |
| Tensile Strength, Yield | 310 MPa | 45,000 PSI |
| Modulus of Elasticity | 200 GPa | 29,000 KSI |
| Hardness, Brinell | 163 | 163 |
| Elongation at Break (in 50 mm) | 16.0% | 16.0% |
| Bulk Modulus (Typical for Steel) | 140 GPa | 20,300 KSI |
| Poissons Ratio | 0.290 | 0.290 |
| Shear Modulus | 80 GPa | 11,600 KSI |
| Grade | EU EN | DIN,WNr | JIS | AFNOR | BS | GOST | ISO | UNS |
| 1045 | C45E (1.1191) | Ck45 | S45C | XC45 XC48H1 | 080M46 CFS8 | 45 | C45E4 | G10450 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Length x Width | Thickness |
|---|---|
| mm | mm |
| 2000 x 1000 | 0.8 |
| 2440 x 1220 | 1.0 |
| 2500 x 1250 | 0.9 |
| 2500 x 1250 | 0.8 |
| 2000 x 1000 | 1.20 |
| 2000 x 1000 | 1.0 |
| 2000 x 1000 | 0.9 |
| 1830 x 1220 | 1.0 |
| 2500 x 1250 | 1.20 |
| Thickness | Length x Width | Mass per Sq m |
|---|---|---|
| mm | mm | Kg/m2 |
| 30.00 | 2000 x 1000 | 235.50 |
| 30.00 | 4000 x 2000 | 235.50 |
| 30.00 | 2500 x 1250 | 235.50 |
| 30.00 | 5000 x 2500 | 235.50 |
| 30.00 | 3000 x 1500 | 235.50 |
| 30.00 | 5000 x 1250 | 235.50 |
| 40.00 | 2000 x 1000 | 314.00 |
| 32.00 | 2000 x 1000 | 251.20 |
| 30.00 | 10000 x 2500 | 235.50 |
| 30.00 | 6000 x 2500 | 235.50 |
| 32.00 | 2500 x 1250 | 251.20 |
| 32.00 | 3000 x 1500 | 251.20 |
| 32.00 | 5000 x 2500 | 251.20 |
| 32.00 | 4000 x 2000 | 251.20 |
| 35.00 | 3000 x 1500 | 274.75 |
| 35.00 | 4000 x 2000 | 274.75 |
| 35.00 | 2500 x 1250 | 274.75 |
| 40.00 | 2500 x 1250 | 314.00 |
| 40.00 | 3000 x 1500 | 314.00 |
| 40.00 | 4000 x 2000 | 314.00 |
These SAE 1045 Steel Sheets and Plates are extensively utilized in industries that demand high strength and wear resistance. They’re commonly found in the manufacturing of machinery parts, gears, shafts, axles, crankshafts, and bolts, thanks to their remarkable mechanical strength and machinability. In the automotive industry, they play a crucial role in engine components and structural applications. The construction and heavy equipment sectors also rely on them for load-bearing parts and structural supports. Moreover, SAE 1045 plates are ideal for tools, jigs, and fixtures, providing durability and reliability, which makes them versatile materials for medium-duty applications across various engineering fields.
