Phanuphong Steel and Plates, a top-notch manufacturer and supplier based in Bangkok, Thailand, specializes in high-quality **ASTM A572 Gr 50 Sheet and Plates**. These products are crafted for structural and industrial applications that demand exceptional strength and durability. With a reputation for precision manufacturing and a commitment to international standards, Phanuphong Steel guarantees that each sheet and plate performs consistently well, even in the toughest conditions. Perfect for construction, bridges, and heavy engineering projects, ASTM A572 Gr 50 sheets and plates offer a fantastic blend of toughness, reliability, and precise dimensions. Catering to both local and international markets, the company provides cost-effective and versatile steel solutions that meet a wide range of engineering and structural needs.
The **ASTM A572 Gr 50 Sheet and Plates** are made from high-strength low-alloy (HSLA) steel, featuring carefully controlled levels of carbon, manganese, phosphorus, and sulfur to ensure optimal strength, toughness, and ductility. Mechanically, they boast impressive tensile strength, yield strength, good elongation, hardness, and impact resistance. Their uniform microstructure and excellent weldability make them perfect for structural frameworks, fabrication projects, and mechanical components that require long-lasting durability and reliable performance in both construction and industrial settings.
| Specifications | : | ASME SA572 / ASTM A572 |
|---|---|---|
| Width | : | 1500-4020mm |
| Length | : | 3000-27000mm |
| Thickness | : | 8-300mm |
| Hardness | : | As per ASME A & NACE MR 175 |
| Impact tested | : | Impact tested -52° C |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Grade | C | Mn | P | V | Ni | Co | S | Si |
| A572 Grade 50 | 0.23 | 1.35 | 0.04 | 0.06 | 0.015 | 0.05 | 0.05 | 0.4 |
| Grade | Thickness | Yield | Tensile | Elongation |
| A572 Grade 50 | 8mm-200mm | MPa -345 min | MPa – 450 | 18-21% |
| Grade | India IS | England BS | Sweden MNC | Belgium NBN | Europe EN | Russia GOST |
| A572 Grade 50 Plate | FE410WC | 43EE | SS14,14，01 | AE 295 DD | S275 J2G3 Fe430 D2 S275NL |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| GRADE | GAUGE (INCHES) | WIDTH (INCHES) | LENGTH (INCHES) |
| A572 | 0.1875 | 96 | 240/480 |
| A572 | 0.2500 | 60/96/120 | 240/480 |
| A572 | 0.3125 | 60/96/120 | 240/480 |
| A572 | 0.3750 | 60/96/120 | 240/480 |
| A572 | 0.5000 | 60/96/120 | 240/480 |
| A572 | 0.6250 | 60/96/120 | 240/480 |
| A572 | 0.7500 | 60/96/120 | 240/480 |
| A572 | 0.8750 | 60/96/120 | 240/480 |
| A572 | 1.0000 | 60/96/120 | 240/480 |
| A572 | 1.1250 | 60/96/120 | 240/480 |
| A572 | 1.2500 | 60/96/120 | 240/480 |
| A572 | 1.5000 | 60/96/120 | 240/480 |
| A572 | 1.7500 | 60/96/120 | 240/480 |
| A572 | 2.0000 | 60/96/120 | 240/480 |
| A572 | 2.2500 | 96 | 240/480 |
| A572 | 2.5000 | 96 | 240/480 |
| A572 | 2.7500 | 96 | 240/480 |
| A572 | 3.0000 | 96 | 240/480 |
| A572 | 3.2500 | 96 | 240 |
| A572 | 3.5000 | 96 | 240 |
| A572 | 3.7500 | 96 | 240 |
| A572 | 4.0000 | 96 | 240 |
| A572 | 5.0000 | 96 | 240 |
| A572 | 6.0000 | 96 | 240 |
These **ASTM A572 Gr 50 Sheet and Plates** are extensively utilized in construction, bridges, buildings, heavy engineering, and infrastructure projects. They are ideal for beams, columns, structural frameworks, and load-bearing components where high strength, toughness, and reliability are essential. With their outstanding mechanical properties, weldability, and resistance to stress, they are well-suited for large-scale industrial and structural applications. Valued for their performance, durability, and cost-effectiveness, ASTM A572 Gr 50 Sheet and Plates are a trusted steel solution for construction, industrial, and engineering projects.
