Phanuphong Steel and Plates, based in Bangkok, Thailand, is a well-respected manufacturer and supplier of top-notch carbon steel piping solutions. They specialize in materials for oil and gas infrastructure, offering Carbon Steel API 5L X46 PSL1 Pipes that are perfect for transporting petroleum, natural gas, and water in tough industrial settings. With a commitment to international API standards, Phanuphong Steel provides pipes that are strong, reliable, and cost-effective. Thanks to a robust supply network and a dedication to customer satisfaction, they cater to clients in the energy, construction, and infrastructure sectors, delivering products designed to perform under high-pressure conditions.
Carbon Steel API 5L X46 PSL1 Pipes are crafted to meet the demands of pipeline transportation systems in the oil, gas, and water industries. Their typical chemical makeup includes Carbon (≤0.26%), Manganese (≤1.40%), Phosphorus (≤0.030%), and Sulfur (≤0.030%). These pipes boast a minimum yield strength of 317 MPa and a minimum tensile strength of 434 MPa. Available in both seamless and welded forms, they are produced under the API 5L specification, PSL1 quality level. Phanuphong Steel guarantees high dimensional accuracy, consistent mechanical properties, and full compliance with inspection and testing standards.
| Grade of material | X46 / L320 (N, M, Q, R) |
| API 5L Gr X46 ERW and HFW | 1/2” NB – 24” NB |
| X46 LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| Standard | ISO 3183 L320/ API 5L X46 |
| API 5L X46 Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2” – 26”) |
| PSL Level | |
| X46 Steel SAW | 16″ – 100″ NB |
| Surface Treatment | Pickling Galvanising Forging Capping Pre turning Powder Coating Degreasing Washing Copper Plating Cementing Chromium – Plating Brushing Nickle – Plating Roller Polishing Grinding Honing Shot Blasting Skiving PE Covering Roller Burnishing |
| Manufacturing process | Welded, Extrusion, Submerged Arc Welded (SAW), Seamless, Electro Fusion Seam Welded (EFSW), Longitudinally Submerged Arc Welded (LSAW), Cold Drawn Seamless (CDS), Hot Finish Seamless (HFS), Horizontal Submerged Arc Welded (HSAW), Electric Resistance Welded (ERW) |
| API 5L X46 PSL1 Pipe end | Squared Ends, Thread Cutting, Socket, Flanged Ends, Beveled End (BE), Cut Grooves, Square Cut, Grooved, Screwed, Vibrator Grinding, Coupling, Plain end (PE), Threaded Ends (Male & Female), Deburring, Chamfering, Buttweld, Pub Joints |
| Certificate | IBR, NACE, EN-10204:3.1, EN-10204:3.2, SSC, Sour-Service, HIC, |
| X46 Carbon Steel Pipe Length | DRL, SRL, 20FT, 40FT, Single Random Length (SRL), Double Random Length (DRL), and Fixed Length 5.8 Meter, 12.0 Meters (40FT), 6.0 Meters (20FT), 11.8 Meters, |
| C | Mn | P | V | Nb | Ti | |
| maxb | maxb | max. | max. | max. | max. | max. |
| 0.28 | 1.20 | 0.030 | 0.030 | c,d | c,d | d |
| Y.S | T.S | ELONGATION |
| Mpa(psi) | Mpa(psi) | |
| min | min | min |
| 245(35 500) | 415(60 200) | 28% |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| NB | DN | OD (inches) | API 5L X46 Pipe Schedule | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SCH 5 | SCH 10 | SCH 20 | SCH 30 | SCH 40 | SCH 60 | SCH 80 | SCH 100 | SCH 120 | SCH 160 | ||||
| 3/4″ | 20 | 1.05 | 0.065 | 0.11 | x | 0.095 | 0.113 | x | x | 0.17 | x | 0.219 | |
| 1″ | 25 | 1.315 | 0.065 | 0.11 | x | 0.114 | 0.133 | x | x | 0.2 | x | 0.25 | |
| 1.1/2″ | 40 | 1.9 | 0.065 | 0.11 | x | 0.125 | 0.145 | x | x | 0.225 | x | 0.281 | |
| 2″ | 50 | 2.375 | 0.065 | 0.12 | x | x | 0.154 | x | x | 0.25 | x | 0.344 | |
| 2.1/2″ | 65 | 2.875 | 0.083 | 0.12 | x | x | 0.203 | x | x | 0.3 | x | 0.375 | |
| 3″ | 80 | 3.5 | 0.083 | 0.12 | x | x | 0.216 | x | x | 0.35 | x | 0.438 | |
| 4″ | 100 | 4.5 | 0.083 | 0.12 | x | x | 0.237 | x | x | 0.437 | x | 0.531 | |
| 5″ | 125 | 5.563 | 0.109 | 0.12 | x | x | 0.258 | x | x | 0.5 | x | 0.625 | |
| 6″ | 150 | 6.625 | 0.109 | 0.13 | x | x | 0.28 | x | x | 0.562 | x | 0.719 | |
| 8″ | 200 | 8.625 | 0.109 | 0.15 | 0.25 | 0.277 | 0.322 | 0.406 | 0.593 | 0.718 | 0.812 | 0.906 | |
| 10″ | 250 | 10.75 | 0.134 | 0.17 | 0.25 | 0.307 | 0.365 | 0.5 | 0.718 | 0.843 | 1.0 | 1.125 | |
| 12″ | 300 | 12.75 | 0.165 | 0.18 | 0.25 | 0.33 | 0.406 | 0.5 | 0.843 | 1.0 | 1.125 | 1.312 | |
Phanuphong Steel is a leading supplier of high-quality Carbon Steel API X46 5L PSL 1 Pipes products in Bangkok, Thailand. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
Carbon Steel API 5L X46 PSL1 Pipes are mainly utilized in pipeline transportation systems for oil, gas, and water over long distances, whether onshore or offshore. These pipes play a crucial role in industries like petrochemical, natural gas processing, power generation, and civil infrastructure. Their impressive strength and resistance to internal pressure make them perfect for cross-country pipelines, refinery piping systems, and water supply lines. Phanuphong Steel provides API 5L X46 pipes that are suitable for a variety of demanding applications, ensuring reliability and performance in every project.
Phanuphong Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Bangkok, Thailand.
