Phanuphong Steel and Plates, a reputable manufacturer and supplier located in Bangkok, Thailand, focuses on providing top-notch Carbon Steel A105 Bars that cater to global industrial needs. Known for their durability, strength, and cost-effectiveness, these bars are engineered to handle tough conditions across various sectors. With state-of-the-art production facilities and rigorous quality control, Phanuphong Steel guarantees that every A105 bar meets international standards. Their dedication to excellence, prompt delivery, and customer satisfaction has established them as a trusted partner for industries in search of high-quality steel solutions in construction, engineering, oil & gas, and other heavy-duty applications.
Carbon Steel A105 Bars are mainly made up of carbon, manganese, phosphorus, sulfur, and silicon, all of which enhance their strength and toughness. These bars are suitable for both ambient and high-temperature applications, providing excellent machinability and hardness. They boast impressive tensile strength, high yield strength, and outstanding impact resistance. With consistent mechanical properties, they can effectively withstand stress, vibration, and pressure. Their chemical makeup boosts durability, while their fine grain structure ensures reliable performance in heat-treated or forged conditions, making them perfect for a variety of industrial engineering tasks.
| Standard | ASTM A105, ASME SA105 |
|---|---|
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Round bar Size | Diameter: 3-~800mm |
| Hex Bar Size | 2-100mm A/F |
| Square Bar Size | 4 to 100mm |
| Angle Bar Size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Threaded Bar Billet Size | 1/2 to 495mm Diameter |
| Rectangular Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Processing | Bar cutting to 650mm |
| Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V |
| A105 | 0.35 | 0.10–0.35 | 0.60–1.05 | 0.035 | 0.040 | 0.12 | 0.40 | 0.30 | 0.40 | 0.08 |
| Grade | Yield Strength, Min (MPa ) | Tensile Strength, Min (MPa) | Elongation, min, % |
| A105 | 250 | 485 | 30 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Phanuphong Steel is a trusted manufacturer and supplier of high-quality Carbon Steel A105 Bars in Bangkok, Thailand. We specialize in premium steel products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability, and performance in critical industrial applications.
| ASTM A105 Round Bar Equivalent | ||
|---|---|---|
| STANDARD | UNS | WERKSTOFF NR. |
| ASTM A105 | K03504 | – |
| US Bar | Metric | Japanese | Canadian/ASTM | ||||
| Diameter(Inch) | Carbon Steel A105 Bar Size | Diameter (millimeter) | Carbon Steel A105 Bar Size | Diameter (millimeter) | Carbon Steel A105 Bar Size | Diameter (millimeter2) | Carbon Steel A105 Bar Size |
| 0.250 | #2 | 5 | 5 | 6 | 6 | 100 | 10M |
| 0.375 | #3 | 5.5 | 5.5 | 10 | 10 | 200 | 15M |
| 0.500 | #4 | 6 | 6 | 13 | 13 | 300 | 20M |
| 0.625 | #5 | 7 | 7 | 16 | 16 | 500 | 25M |
| 0.750 | #6 | 8 | 8 | 19 | 19 | 700 | 30M |
| 0.875 | #7 | 9 | 9 | 22 | 22 | 1000 | 35M |
| 1.000 | #8 | 10 | 10 | 25 | 25 | 1500 | 45M |
| 1.125 | #9 | 11 | 11 | 29 | 29 | 2500 | 55M |
| 1.250 | #10 | 12 | 12 | 32 | 32 | Â | Â |
| 1.375 | #11 | 14 | 14 | 35 | 35 | Â | Â |
| 1.500 | #12 | 16 | 16 | 38 | 38 | Â | Â |
| 1.625 | #13 | 18 | 18 | 41 | 41 | Â | Â |
| 1.750 | #14 | 20 | 20 | 44 | 44 | Â | Â |
| 1.875 | #15 | 22 | 22 | 48 | 48 | Â | Â |
| 2.000 | #16 | 25 | 25 | 51 | 51 | Â | Â |
| 2.250 | #18 | 28 | 28 | 57 | 57 | Â | Â |
| Â | Â | 32 | 32 | Â | Â | Â | Â |
| Â | Â | 36 | 36 | Â | Â | Â | Â |
| Â | Â | 40 | 40 | Â | Â | Â | Â |
| Â | Â | 44 | 44 | Â | Â | Â | Â |
| Â | Â | 50 | 50 | Â | Â | Â | Â |
| Diameter in inch | Size in inch/MM | Weight Lbs/ft & Kg/M |
| 1/16 | 0.0625 1.5875 | 0.010 / 0.01488 |
| 1/8 | 0.125 3.175 | 0.042 / 0.062496 |
| 3/32 | 0.0938 2.38252 | 0.0240 / 0.035712 |
| 5/32 | 0.1563 3.97002 | 0.065 / 0.09672 |
| 7/32 | 0.2188 5.55752 | 0.128 / 0.190464 |
| 3/16 | 0.1875 4.7625 | 0.094 / 0.139872 |
| 1/4 | 0.25 6.35 | 0.167 / 0.248496 |
| 5/16 | 0.3125 7.9375 | 0.260 / 0.38688 |
| 9/32 | 0.2813 7.14502 | 0.211 / 0.313968 |
| 3/8 | 0.375 9.525 | 0.376 / 0.559488 |
| 1/2 | 0.5 12.7 | 0.668 / 0.993984 |
| 7/16 | 0.4375 11.1125 | 0.512 / 0.761856 |
| 9/16 | 0.5625 14.2875 | 0.844 / 1.255872 |
| 11/16 | 0.6875 17.4625 | 1.264 / 1.880832 |
| 5/8 | 0.625 15.875 | 1.043 / 1.551984 |
| 3/4 | 0.75 19.05 | 1.502 / 2.234976 |
| 7/8 | 0.875 22.225 | 2.045 / 3.04296 |
| 13/16 | 0.8125 20.6375 | 1.761 / 2.620368 |
| 15/16 | 0.9375 23.8125 | 2.35 / 3.4968 |
| 1 1/16 | 1.0625 26.9875 | 3.012 / 4.481856 |
| 1 | 1 25.4 | 2.671 / 3.974448 |
| 1 1/8 | 1.125 28.575 | 3.38 / 5.02944 |
| 1 1/4 | 1.25 31.75 | 4.173 / 6.209424 |
| 1 3/16 | 1.1875 30.1625 | 3.77 / 5.60976 |
| 1 5/16 | 1.3125 33.3375 | 4.598 / 6.841824 |
Carbon Steel A105 Bars find extensive use in industries that demand strength and durability under high stress. They’re commonly found in the production of flanges, fittings, and valves, particularly in oil and gas pipelines, petrochemical facilities, and power generation systems. In construction and structural engineering, these bars are integral to frameworks, shafts, and fasteners. Additionally, they are utilized in machinery parts, automotive components, and pressure systems due to their resistance to mechanical wear and stress. Their versatility and reliability make them crucial for essential applications in heavy-duty industries around the globe.
