Phanuphong Steel and Plates stands out as a top manufacturer and supplier based in Bangkok, Thailand, specializing in high-quality steel products and tubing tailored for critical industrial needs. One of their standout products, Alloy Steel T9 Tubing, is well-known for its impressive strength, durability, and precision engineering. These tubes are designed to perform reliably even in high-pressure and high-temperature environments, making them essential for sectors like oil and gas, petrochemical, power generation, and automotive. Phanuphong Steel is committed to delivering superior material quality, precise dimensions, and timely deliveries, earning a reputation as a trusted partner for both local and international industrial and infrastructure projects.
Alloy Steel T9 Tubing is primarily made from carbon steel, enhanced with chromium, molybdenum, and manganese, which boosts its mechanical strength, hardness, and resistance to corrosion. It boasts excellent tensile and yield strength, toughness, and resistance to wear, oxidation, and thermal stress. This tubing is built to last under tough conditions and offers reliable weldability. These characteristics ensure long-lasting performance and structural integrity, making Alloy Steel T9 Tubing a go-to choice for high-pressure and high-temperature applications in the oil and gas, petrochemical, and power generation sectors.
| ASTM A213 T9 Specification & Standard | ASTM A213 T9, ASME SA213 T9 (with IBR Test Certificate) |
|---|---|
| SA 213 Gr T9 Specification | ASTM A213 & ASTM A209 BS/3059/ 90/ Part II/ 620 & 622 DIN/ 17175/ 13CrMo44 DIN/ 17175/ 10CrMo910 DIN/ 17175/ 15Mo3 |
| T9 Steel Tube Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| A213 Grade T9 Tubing Size | 6.35 mm OD to 101.6 mm OD |
| SA213 Grade T9 Pipe Thickness | 3-12mm |
| ASTM A213 Grade T9 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| Craft | Cold rolled and Cold drawn |
| SA213 Grade T9 Tube Type | Seamless / ERW / Welded / Fabricated |
| A213 Grade T9 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| T9 Steel Grade Material Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| SA213 T9 Steel Tube Length | Standard Double & In Cut length also. |
| T9 Steel Grade Tube End | Plain End, Beveled End, Treaded |
| SA213 Grade T9 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Specialized in |
|
| SA213 T9 Steel Tube Application & uses | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| SA213 T9 Composition |
0.15 max |
0.30~0.60 |
0.025 |
0.025 |
0.25-1.0 |
0.90~1.10 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| T9 | 415 min | 205 min | 30 min | 179 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Phanuphong Steel is a trusted manufacturer and supplier of premium Alloy Steel T5 Tubing in Bangkok, Thailand. We specialize in high-quality steel materials and offer a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a commitment to timely delivery and outstanding customer service, we use only the finest raw materials to ensure exceptional performance in demanding industrial applications. Contact us today for all your Alloy Steel T5 Tubing needs!
You’ll find Alloy Steel T9 Tubing widely utilized in oil and gas pipelines, petrochemical facilities, power generation equipment, hydraulic and pneumatic systems, and automotive applications. It’s perfect for transporting high-pressure fluids, functioning as heat exchangers, providing structural support, and serving as critical components in machinery. With its remarkable mechanical strength, corrosion resistance, and durability, it’s well-suited for fabrication, engineering, and construction tasks in demanding industrial settings. Thanks to its long service life and consistent performance under extreme conditions, Alloy Steel T9 Tubing is the preferred choice for industries that need safe, efficient, and reliable tubing solutions.
Phanuphong Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Bangkok, Thailand.
