Phanuphong Steel and Plates, located in Bangkok, Thailand, is a reliable manufacturer and supplier known for its high-strength steel solutions. With a solid reputation for quality, dependability, and timely delivery, the company provides a diverse range of industrial-grade steel products, including the highly sought-after S650MC Sheets and Plates. These products are specifically designed for demanding applications and are engineered to comply with international standards and industry needs. Serving sectors like automotive, structural, and heavy machinery, Phanuphong guarantees that each product delivers exceptional performance and durability. As a leading steel supplier in Southeast Asia, the company is recognized for its technical know-how and commitment to customer satisfaction.
S650MC is a high-strength low-alloy (HSLA) thermomechanically rolled steel grade. Its chemical makeup features carbon (≤0.12%), manganese (≤2.10%), phosphorus (≤0.025%), sulfur (≤0.015%), along with micro-alloying elements like niobium, titanium, and vanadium. On the mechanical side, it boasts a minimum yield strength of 650 MPa and tensile strength between 700–900 MPa, along with impressive elongation and formability. This steel is perfect for cold-forming and offers outstanding weldability and toughness, even at low temperatures. The name “S650MC Sheet and Plate” signifies its strength class and its suitability for challenging fabrication and structural tasks.
| Material | Strenx 650 |
| Standards | EN 10149-2, EN 10051, EN 10163-2 |
| Thickness | 2.00 to 10.00 milimeter |
| Width | up to 1600 milimeter |
| Length | Up to 16000 milimeter |
| C | Mo | S | B | Mn | Si | Alt | P | Nb | V | Ti |
| ≤0.12 | ≤0.50 | ≤0.015 | ≤0.005 | ≤2.00 | ≤0.60 | ≤0.015 | ≤0.025 | ≤0.09 | ≤0.20 | ≤0.22 |
Elongation | tensile strength | 180°bend | Yield Strength(MPa) |
10 | 700-880 | d=2a | 650 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Thickness (mm) | Weight Theoretical | Weight Theoretical | ||
| Kg/m2 | Kg/ft2 | Kg/ft2 | Kg/m2 | |
| 0.90 | 7.065 | 0.656 | 4.376 | 47.100 |
| 0.80 | 6.280 | 0.583 | 4.011 | 43.175 |
| 0.75 | 5.888 | 0.547 | 3.646 | 39.250 |
| 1.0 | 7.850 | 0.729 | 4.740 | 51.025 |
| 1.9 | 14.915 | 1.386 | 10.916 | 117.500 |
| 1.2 | 9.420 | 0.875 | 5.470 | 58.875 |
| 1.6 | 12.560 | 1.167 | 8.387 | 90.275 |
| 1.4 | 10990 | 1.021 | 6.928 | 74.575 |
| 2.2 | 17.270 | 1.604 | 12.398 | 133.450 |
| 1.3 | 10.205 | 0.948 | 5.834 | 62.800 |
| 1.7 | 13.345 | 1.240 | 8.751 | 94.200 |
| 1.5 | 11.775 | 1.094 | 7.293 | 78.500 |
| 1.1 | 8.635 | 0.802 | 5.105 | 54.950 |
| 2.3 | 18.055 | 1.677 | 13.127 | 141.300 |
| 1.8 | 14.130 | 1.313 | 10.210 | 100.900 |
| 3.5 | 27.475 | 2.553 | 15.315 | 164.850 |
| 2.0 | 15.700 | 1.459 | 11.669 | 125.600 |
| 2.5 | 19.625 | 1.823 | 13.856 | 149.150 |
| 3.0 | 23.550 | 2.188 | 14.586 | 157.000 |
| 4.0 | 31.400 | 2.917 | 16.044 | 172.700 |
S650MC Sheets and Plates find extensive use in industries that demand high strength, lightweight materials, and excellent formability. They are commonly used in structural components for heavy commercial vehicles, automotive chassis and frames, cranes, trailers, and agricultural machinery. Thanks to their high yield strength, these sheets and plates allow for thinner structural parts, which helps reduce overall material usage and costs. Moreover, S650MC is well-suited for cold forming and welding processes, making it a versatile choice for various applications.
Phanuphong Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Bangkok, Thailand.
