Phanuphong Steel and Plates, located in the vibrant city of Bangkok, Thailand, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Carbon Steel EN-45 Bars, serving both local and international markets. With a strong focus on precision engineering, cutting-edge technology, and rigorous quality standards, this company consistently delivers durable and high-performance bars that meet a variety of industrial needs. Renowned for their strength, reliability, and versatility, these EN-45 bars find applications across the automotive, construction, and engineering sectors. Phanuphong Steel and Plates prides itself on timely deliveries, competitive pricing, and exceptional customer service, making it a go-to choice for quality steel solutions around the globe.
Carbon Steel EN-45 Bars are primarily made up of carbon, manganese, silicon, and trace elements, striking a perfect balance between strength and toughness. They boast impressive mechanical properties, including high tensile strength, excellent elasticity, and remarkable wear resistance. These bars are hard enough to endure fatigue and stress in challenging environments, and their heat-treatable nature boosts their durability and performance. With great machinability and resilience, EN-45 bars offer reliable mechanical stability, making them ideal for applications that require strength, flexibility, and a long service life.
| Grade | EN45 |
|---|---|
| Specification | BS970 1.0904 55Si7 55S6 55Si2Mn ASTM 9255 |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Section | 3.0 to 12.0mm thickness |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground,smooth turned, peeled, slit rolled edge, hot rolled, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | EN45 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Processing | Bar cutting to 650mm |
| Form | EN45 Welding Rod, Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Element | En42J |
| C | 0.75 – 0.90% |
| Mn | 0.50 – 0.90% |
| Si | 0/1 – 0.35 |
| S | 0.04% Max |
| P | 0.04% Max |
|
ULTIMATE TENSILE STRENGTH, S. (MPA) |
621 |
|---|---|
|
Modulus of elasticity, E (Gpa) |
204 |
|
Fatigue strength coefficient, of (Mpa) |
948 |
|
Fatigue strength exponent, b |
-0.092 |
|
Fatigue ductility coeffient ,ef |
0.26 |
|
Fatigue ductility exponent,c |
-0.445 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
Cut to size on request (tolerance +2/-0 mm). Standard lengths of EN45 Bars 2000 mm up to 6000 mm available
5.0 | 45.0 |
6.0 | 50.0 |
7.0 | 55.0 |
8.0 | 60.0 |
9.0 | 65.0 |
10.0 | 70.0 |
12.0 | 75.0 |
16.0 | 80.0 |
20.0 | 90.0 |
25.0 | 100.0 |
30.0 | 130.0 |
35.0 | 160.0 |
40.0 | 200.0 |
In the automotive industry, Carbon Steel EN-45 Bars are widely used to manufacture components like springs, leaf springs, and suspension systems, thanks to their outstanding elasticity and toughness. In construction, they play a crucial role in structural frameworks, reinforcement, and load-bearing equipment. Additionally, these bars are essential in industrial machinery, tools, and engineering applications that demand high tensile strength and fatigue resistance. Their versatility extends to railways, agricultural equipment, and heavy-duty mechanical systems, ensuring reliability and long-lasting performance across a range of sectors.
