Phanuphong Steel and Plates, a reputable manufacturer and supplier based in Bangkok, Thailand, is dedicated to providing top-notch S355JO+N steel sheets and plates for a variety of industries. With a strong emphasis on durability, reliability, and precision, this company delivers materials that adhere to international standards for construction, engineering, and fabrication projects. Renowned for their exceptional strength and weldability, S355JO+N steel sheets and plates are a popular choice for structural applications. Phanuphong Steel guarantees consistent quality, timely deliveries, and competitive pricing, making them a trusted partner for clients across different sectors in need of high-grade steel solutions.
S355JO+N steel sheets and plates are alloy structural steels that include elements like carbon, manganese, silicon, and controlled trace impurities such as phosphorus and sulfur. This specific composition boosts their toughness and weldability. On the mechanical side, they showcase impressive yield strength around 355 MPa, tensile strength ranging from 470 to 630 MPa, and solid impact resistance at 0°C, ensuring they hold up well under tough conditions. Thanks to the normalized rolling (N) process, the steel achieves uniform mechanical properties, dimensional stability, and resistance to brittle fractures, making it perfect for structural and fabrication uses.
Item : S355JO+N – Offshore & Structural Steel Plate
Thickness : 5mm-150mm
Width : 1000mm-4500mm
Length : 3000mm-18000mm or as custom’s request
Material : En 10025-2 Steel Plate, S355JO+N Steel Plate
Technique : hot rolled
Standard : EN 10025-2:2004
C | Si | Mn | P | S | N | Cu | CEV |
0.22 max | 0.55 max | 1.6 max | 0.035 max | 0.035 max | 0.012 max | 0.55 max | 0.47 max |
| Nominal thickness (mm): |
to 3 |
3 – 100 |
100 – 150 |
150 – 250 |
– |
– |
– |
– |
| Rm – Tensile strength (MPa) Flat and long products |
510-680 |
470-630 |
450-600 |
450-600 |
– |
– |
– |
– |
| Nominal thickness (mm): |
to 16 |
16 – 40 |
40 – 63 |
63 – 80 |
80 – 100 |
100 – 150 |
150 – 200 |
200 – 250 |
| ReH – Minimum yield strength (MPa) Flat and long products |
355 |
345 |
335 |
325 |
315 |
295 |
285 |
275 |
|
KV – Impact energy (J) longitud., |
-20° |
0° |
+20° |
– |
– |
– |
– |
– |
|
27 |
27 |
27 |
– |
– |
– |
– |
– |
|
|
Nominal thickness (mm): |
Mar-40 |
40 – 63 |
63 – 100 |
100 – 150 |
150 – 250 |
– |
– |
– |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
These S355JO+N steel sheets and plates find extensive applications in construction, infrastructure, and heavy engineering sectors. They are particularly well-suited for building bridges, structures, offshore installations, and pressure vessels due to their strength and durability. In the automotive and shipbuilding industries, they are essential for creating chassis, frames, and hull structures. Their excellent weldability also makes them ideal for fabrication and custom structural designs. Additionally, power plants, mining, and equipment manufacturing industries depend on these plates for machinery, support structures, and load-bearing applications, showcasing their versatility and reliability across various fields.
