Phanuphong Steel and Plates, located in the vibrant city of Bangkok, Thailand, stands out as a top-notch manufacturer and supplier of EN 19 Sheets and Plates. They specialize in delivering high-performance alloy steel solutions tailored for critical engineering applications. Known for its impressive strength, toughness, and wear resistance, EN 19 is a go-to material in industries that require durable and reliable products. Phanuphong Steel and Plates is committed to upholding strict quality standards and precision in manufacturing, ensuring that their sheets and plates align with global specifications. With a keen focus on durability and performance, they supply EN 19 products to various sectors, including automotive, construction, aerospace, and heavy engineering, all around the globe.
EN 19 Sheets and Plates are crafted from alloy steel that includes chromium, molybdenum, and manganese, with a carbon content ranging from about 0.35% to 0.45%. This well-balanced composition boosts toughness, wear resistance, and strength while still allowing for good machinability. On a mechanical level, EN 19 showcases excellent tensile strength, impact resistance, and fatigue resistance. It can also be heat-treated to enhance hardness and durability without sacrificing ductility. Thanks to its superior hardenability and toughness, EN 19 is perfect for heavy-duty applications, ensuring a long service life and reliable performance in challenging engineering and industrial settings.
Grade : EN19 Low Alloy Steel Plate
Thickness : from 3mm up to as thick as 150mm
Length :3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Process of Manufacturing : Hot-Rolled (HR)
| Â Grade | Mn | Si | C | Cr | P | Ni | S | Mo |
| EN – 19 | .50 – .80 | .10 – .35 | .35 – .45 | .90 – 1.40 | .040 | – | .040 | .20 – .40 |
| Max Stress | 850-1000 n/mm2 | |
| Impact KCV | 55 Joules Min | |
| Hardness | 248-302Â HB | |
| Yield Stress | 700Â N/mm2Â Min | |
| 0.2% Proof Stress | 680Â N/mm2Â Min | Â subject to ruling section |
| Elongation | 9% Min |
| GRADE | BS 970 1991 | BS 970 1955 EN | AISI/SAE | Werkstoff |
| EN 19 | 708M40 | EN19 | 4140 | 1.7225 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Across various industries, EN 19 Sheets and Plates are highly sought after for applications that demand exceptional strength and toughness. In the automotive sector, they are commonly used for gears, shafts, axles, and crankshafts, thanks to their outstanding wear resistance. In construction and engineering, EN 19 plays a vital role in structural components, fasteners, and parts for heavy machinery. The aerospace and marine industries rely on it for critical components that face high stress and impact. Additionally, it finds its place in mining equipment, power generation, and railway components, ensuring reliability even in tough conditions. Its versatility and durability make EN 19 a top choice across a wide range of sectors.
