Phanuphong Steel and Plates, based in Bangkok, Thailand, has made a name for itself as a top-notch manufacturer and supplier of high-quality **Carbon Steel Forged Socket Weld Pipe Fittings**. Thanks to cutting-edge technology and a wealth of industry experience, this company produces fittings that adhere to international standards for strength, precision, and performance. Known for their durability and resistance to wear, these fittings excel in high-pressure applications. Phanuphong Steel and Plates is dedicated to delivering dependable products that serve a variety of industries, ensuring customer satisfaction through consistent quality, competitive pricing, and timely delivery both locally and globally.
**Carbon Steel Forged Socket Weld Pipe Fittings** are primarily made up of carbon, iron, manganese, along with trace amounts of sulfur and phosphorus. The carbon boosts strength and hardness, while manganese adds toughness and wear resistance. These fittings showcase impressive tensile strength, yield strength, and impact resistance. They also offer excellent ductility and machinability, making them perfect for welding and forming processes. With their well-balanced chemical makeup and dependable mechanical properties, Carbon Steel Forged Socket Weld Pipe Fittings are perfect for tough conditions that demand durability and structural integrity.
| Specifications | ASTM A105 | A350 LF2 | A694 | A350 LF3 |
|---|---|
| Size Ranges | 1/8 inch – 4 inch (DN6~DN100) |
| Pressure Classes | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type of Forged | NPT, BSP, BSPT Fittings |
| Dimension Standard | ASME 16.11, MSS SP-79, MSS SP-95, 83, 95, 97, BS 3799 |
| Type of Connection | Welding |
| Element | Composition %, Note C |
|---|---|
| Copper | .40 max, note A |
| Carbon | .35 max |
| Silicon | .10-35 |
| Manganese | .60-1.05 |
| Chromium | .30 max, note A,B |
| Phosphorus | .035 max |
| Molybdenum | .12 max, note A,B |
| Sulfur | .040 max |
| Nickel | .40 max, note A |
| Vanadium | .08 max, note A |
| Property | |
|---|---|
| Reduction of area, min: | 30% min |
| Tensile Strength, min: | 70,000 psi (485 MPa] |
| Min. Yield Point: | 36,000 psi [250 MPa] |
| Hardness, HB, max | 187 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Phanuphong Steel is a top manufacturer and supplier of high-quality Carbon Steel Forged Socket Weld Pipe Fittings products in Bangkok, Thailand. Specializing in steel solutions, we provide a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel. Our offerings include Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Known for our reliable delivery and superior customer service, we are committed to offering top-tier steel materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your steel needs.
You’ll find **Carbon Steel Forged Socket Weld Pipe Fittings** in various industries, including oil and gas, petrochemicals, power generation, and shipbuilding. They play a crucial role in creating leak-proof and reliable pipe connections in high-pressure and high-temperature settings. In refineries and chemical plants, these fittings ensure safe fluid handling, while in construction and mechanical systems, they facilitate smooth flow management. Their toughness and durability make them ideal for pipelines, hydraulic systems, and heavy machinery. Plus, their cost-effectiveness and strength make them a go-to choice for applications that require long-lasting performance.
Phanuphong Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Bangkok, Thailand.
