Phanuphong Steel and Plates, a reputable manufacturer and supplier based in Bangkok, Thailand, is dedicated to delivering top-notch Carbon Steel BS3601 Pipes for a variety of industrial uses. Renowned for their reliability, durability, and adherence to international standards, these pipes are a go-to choice in industries that demand robust and efficient piping solutions. With state-of-the-art manufacturing facilities and rigorous quality control measures, Phanuphong Steel guarantees pipes that offer outstanding performance and a long service life. They provide a broad selection of sizes and specifications, catering to the diverse needs of their customers, making them a trusted source for Carbon Steel BS3601 Pipes across various sectors.
The composition of Carbon Steel BS3601 Pipes includes carbon, manganese, silicon, phosphorus, and sulfur, along with balanced alloying elements that boost strength and machinability. These pipes showcase impressive tensile strength, good impact resistance, and moderate hardness, ensuring they hold up well in challenging environments. Their mechanical properties feature high yield strength, good elongation capacity, and toughness, even under fluctuating temperature conditions. Manufactured to exact dimensional standards, these pipes are ideal for pressure-bearing applications, ensuring safety, reliability, and structural integrity in industrial and engineering projects.
| Dimensions | ASTM, ASME and API |
| Thickness | 50mm to 7.00mm, custom OD and thickness available on request |
| End | Plain End, Beveled End, Treaded |
| Length | Single Random, Double Random & Required Length, Custom Size – according to customer’s requirement |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Types | Seamless / ERW / Welded / Fabricated / CDW |
| Outer Diameter | 19.05mm to 127mm |
| Wall Thickness | 0.8mm to 6.0mm |
| Length | 6mtr/ 12mtr or Cut to Length |
| Capacity | 7000 Mt/Month |
Grade | Mfg. Process | Chemical Composition(%) | ||||||||
C | Si | Mn | P | S | Ni | Cr | Mo | Others | ||
BW320 | B | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW320 | E | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW360 | E | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.050Max | – | – | – | – |
ERW430 | E | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | – |
S360 | S | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
S430 | S | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
SAW430 | A | 0.25Max | 0.50Max | 1.20Max | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
Grade
|
Tensile Test MPa or N/mm2 |
Remaks (Similar to JIS) |
Possibility Temperature |
|
|
Min Yield point |
Tensile Strength |
|||
|
BW320 |
195 |
320~460 |
– |
|
|
ERW320 |
195 |
320~460 |
– |
|
|
ERW360 |
235 |
360~500 |
(STPG370) |
|
|
ERW430 |
195 |
430~570 |
(STPG410) |
|
|
S360 |
235
225
215 |
360~550 |
(STPG310) |
|
|
S430 |
275
265
255 |
430~570 |
(STPG410) |
|
|
SAW430 |
275
265
255 |
430~570 |
(STPY400) |
|
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Nominal Pipe Size (inches) | Outer Diameter (mm) | Wall Thickness (mm) | Weight (kg/m) |
|---|---|---|---|
| 1/2 | 21.3 | 2.11 | 1.21 |
| 3/4 | 26.7 | 2.11 | 1.62 |
| 1 | 33.4 | 2.77 | 2.49 |
| 1 1/4 | 42.2 | 3.56 | 3.74 |
| 1 1/2 | 48.3 | 3.68 | 4.46 |
| 2 | 60.3 | 3.91 | 5.71 |
| 3 | 88.9 | 5.49 | 11.29 |
| 4 | 114.3 | 6.02 | 16.07 |
| 6 | 168.3 | 7.11 | 28.26 |
Jaxon Steel is a leading manufacturer and exporter of high-quality Carbon Steel BS3601 Pipes in Bangkok, Thailand. We offer a comprehensive range of steel solutions, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product portfolio includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliability and outstanding customer service, we are dedicated to delivering top-tier steel products designed for demanding industrial applications, ensuring long-lasting durability and superior performance. Phanuphong Steel is your trusted partner for all Carbon Steel BS3601 Pipe needs.
Carbon Steel BS3601 Pipes are favored across multiple industries for their strength, cost-effectiveness, and dependability. They find common use in power plants, oil refineries, petrochemical industries, and water supply systems where robust performance is essential. Additionally, these pipes are utilized in gas transportation, boiler installations, heat exchangers, and pressure vessels. Their versatility allows them to effectively convey both fluids and gases in low to medium pressure settings. Furthermore, they are employed in construction, engineering projects, and manufacturing industries, ensuring reliable service life and efficiency in critical operational conditions.
Phanuphong Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Bangkok, Thailand.
