Phanuphong Steel and Plates, a well-respected manufacturer and supplier located in Bangkok, Thailand, specializes in providing top-notch **Carbon Steel ASME SA 822 Tubing** tailored for a variety of industrial needs. Renowned for their precision engineering and commitment to international standards, this company delivers tubing solutions that are not only reliable and durable but also cost-effective. Thanks to their advanced production methods and rigorous quality checks, Phanuphong Steel guarantees consistency and high performance in every product. Their **ASME SA 822 Tubing** is crafted to meet the demands of industries that require high-strength, dependable tubing, making it a go-to choice for global engineering, construction, and manufacturing sectors.
The **Carbon Steel ASME SA 822 Tubing** is primarily made up of carbon, with carefully controlled levels of manganese, sulfur, and phosphorus, striking a perfect balance between strength and machinability. This composition ensures excellent weldability, toughness, and durability. Mechanically, the tubing boasts impressive tensile strength, impact resistance, and ductility, making it ideal for heavy-duty applications. With a consistent microstructure and outstanding hardness properties, it effectively withstands pressure and temperature fluctuations. These characteristics ensure that the tubing performs reliably in demanding environments across various industrial sectors.
| Product | ASTM A822 Seamless Steel Tubes |
| Specification | ASTM A822 / ASME SA822 |
| Standard | ASME SA822 is the standard applicable to Seamless cold drawn low carbon steel heat exchanger and condenser tubes |
| Size OD (In mm) | 3/4” (19.05mm), 1” (25.4mm), 1¼” (31.75mm), 1½” (38.1mm), 2” (50.8mm), 2½” (63.5mm), 3” (76.2mm) |
| Wall Thickness (BWG, mm) | 16BWG (1.651mm), 14BWG(2.108mm), 12BWG(2.769mm), 10BWG(3.404mm), 8BWG(4.191mm) |
| Application | For high, middle, low pressure boiler and pressure purposes |
| Length | 5800mm; 6000mm; 6096mm; 7315mm; 11800mm; and so on. Max length: 27000mm, also U bending can be offered |
| Product Marking | ASTM A822 or ASME SA822, size, heat no., Lot No. and Manufacture name or logo. |
| Other Testing | Hydrostatic Test |
| Type | Seamless – Hot Rolled / Cold Drawn |
| Form | Round |
| International Standards | ASME, API, EN, DIN, ISO |
| End | Plain End, Beveled End, Coupling |
| Inspection | Third Party Inspection, Buyer Inspection |
| Packing | Weaving Bag, Seaworthy Bundles, Wooden Case if required |
| Specials | Sizes and Specification other than above can be manufactured on request |
| Certification | EN 10204 3.1 |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.18 | – | 0.27-0.63 | 0.048 | 0.058 | – | – | – | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Phanuphong Steel is a trusted manufacturer and supplier of high-quality Carbon Steel ASME SA 822 Tubing in Bangkok, Thailand. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to reliable delivery and exceptional customer service, Phanuphong Steel provides top-grade materials that ensure superior performance in various industrial applications. Trust us for all your Carbon Steel ASME SA 822 Tubing needs.
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 310 | – | 45 | 35 | ||
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| – | EN P195TR2 Grade 10216-1 | – | ASTM A822 – | ASME SA 822 – | – |
You’ll find the **Carbon Steel ASME SA 822 Tubing** widely utilized in industries like construction, power generation, oil and gas, automotive, and mechanical engineering. Its strength and durability make it perfect for pipelines, boilers, pressure vessels, and parts of heavy-duty machinery. In fabrication and structural projects, the tubing is appreciated for its formability and weldability. It’s also used in transport equipment, mechanical frameworks, and industrial applications where both cost-effectiveness and reliability are essential. Its versatility and robust performance make it a top choice for critical engineering and manufacturing operations.
Phanuphong Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Bangkok, Thailand.
