Phanuphong Steel and Plates is a top-notch manufacturer and supplier located in Bangkok, Thailand, known for delivering high-quality steel products to a variety of industries. One of their standout offerings is the API 5L Grade B PSL1 Pipe, which is celebrated for its reliability and compliance with international standards. These pipes are specifically designed for oil, gas, and fluid transportation systems, and they’re highly regarded for their strength, durability, and overall performance. Phanuphong Steel prides itself on providing superior material quality, competitive pricing, and prompt delivery, making them a go-to partner for energy, construction, and infrastructure projects not just in Thailand, but beyond.
The API 5L Grade B PSL1 Pipe is mainly made from carbon steel, with carefully controlled levels of manganese, phosphorus, and sulfur, striking the perfect balance between strength and weldability. It boasts a minimum yield strength of 245 MPa and a tensile strength that ranges from 415 to 760 MPa, ensuring dependable mechanical performance in various conditions. This pipe is known for its excellent toughness, good formability, and wear resistance, making it a great choice for fluid transportation. Manufactured using both seamless and welded processes, it adheres to strict PSL1 specifications, guaranteeing safety and efficiency in demanding pipeline systems.
| API 5l Gr B Psl2 ERW and HFW | 1/2” NB – 24” NB |
| API 5L Gr B SAW | 16″ – 100″ NB |
| API 5L Grade B Psl1 LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| API 5L Grade B Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2″ – 26″) |
| OD | 21.3MM ~ 762MM |
| Killed Carbon Steel API 5L Pipe end | BOE-Beveled One End TOE -Treaded One End, BE -Beveled end, BLE -Bevel large end, BSE -Bevel small end, TBE -Treaded Both Ends, BBE -Bevel both ends, POE -Plain One End, PBE -Plain Both Ends, API 5L Grade B Welded Pipe |
| Wall Thickness of API 5L Grade B Pipe | 4.5mm to 60mm |
| API 5L Grade B Material Cutting Techniques | Sawing, Laser, Burrless Cuts, Tapping, Water-Jet, API 5L Gr B Nace Pipe |
| Different methods used by API 5L Grade B Pipe manufacturers’ | Longitudinally Submerged Arc Welded (LSAW), Cold Drawn Seamless (CDS), 100% X Ray/ Gamma Ray Welded Welded, CDW, Submerged Arc Welded (SAW), Extrusion, Fabricated, Seamless, Electro Fusion Seam Welded (EFSW), Horizontal Submerged Arc Welded (HSAW), Electric Resistance Welded (ERW), Hot Finish Seamless (HFS), API 5L Grade B Schedule 80 Pipe |
| Surface Treatment of API 5L Grb Pipe |
|
| Pipe API 5L Gr B Schedule | SCH-40, SCH-80S, SCH-40S, SCH-10S, SCH-5, SCH-80, SCH160, SCH-XS, SCH-STD, SCH-5S, SCH-10, SCH-XXS, API 5L Gr B Smls Pipe |
| L245 Grade B Pipe Length | 12000mm, 20FT, Single Random Length (SRL), 6000mm, 40FT, DRL, Double Random Length (DRL), 2000mm, Custom Length SRL, 3000mm, API 5L Gr.B PSL2- SAW Pipes |
| Chemical Composition % | ||||||||
| PSL1 | PSL2 | |||||||
| Grade | C (Max.) | Mn(Max.) | P(Max.) | S(Max.) | C (Max.) | Mn(Max.) | P(Max.) | S(Max.) |
| A | 0.22 | 0.90 | 0.03 | 0.03 | 0.22 | 1.20 | 0.025 | 0.015 |
| B | 0.26 | 1.20 | 0.03 | 0.03 | 0.22 | 1.30 | 0.025 | 0.015 |
| X42 | 0.26 | 1.30 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X46 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X52 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X56 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X60 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.45 | 0.025 | 0.015 |
| X65 | 0.26 | 1.45 | 0.03 | 0.03 | 0.22 | 1.65 | 0.025 | 0.015 |
| X70 | 0.26 | 1.65 | 0.03 | 0.03 | 0.22 | 1.85 | 0.025 | 0.015 |
| PSL 1 | |||||
|---|---|---|---|---|---|
| Grade | Tensile Strength(Min.) | Yield Strength(Min.) | Elongation | ||
| MPa | Ksi | MPa | Ksi | E=1944 A 0.2 /U 0.9 | |
| B | 414 | 60 | 241 | 35 | |
| X52 | 455 | 66 | 359 | 52 | |
| X60 | 434 | 63 | 414 | 60 | |
| X65 | 455 | 66 | 448 | 65 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Phanuphong Steel is a top manufacturer and supplier of high-quality API 5L Grade B PSL1 Pipe products in Bangkok, Thailand. Specializing in steel solutions, we provide a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel. Our offerings include Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Known for our reliable delivery and superior customer service, we are committed to offering top-tier steel materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your steel needs.
You’ll find the API 5L Grade B PSL1 Pipe widely utilized in sectors like oil and gas, petrochemicals, water supply, and construction. Its main uses include transporting oil, natural gas, and water through long-distance pipelines, whether onshore or offshore. Thanks to its strength and weldability, it’s an ideal option for structural applications, fabrication work, and infrastructure projects. Plus, it’s suitable for mechanical and engineering tasks such as scaffolding, piling, and support systems. With its durability, cost-effectiveness, and adherence to global standards, the API 5L Grade B PSL1 Pipe guarantees long-lasting performance in critical operations.
