Phanuphong Steel and Plates, a top-notch manufacturer and supplier located in Bangkok, Thailand, is all about high-quality Alloy Steel Grade 5 Coils. Known for their precision engineering and durability, these coils are crafted to meet international standards, ensuring they perform consistently across a range of industrial applications. Phanuphong Steel prides itself on superior quality control, timely delivery, and tailored solutions for clients in various sectors, from construction to heavy machinery. With a strong focus on innovation and excellence, the company delivers reliable steel products that boost structural integrity, operational efficiency, and long-lasting performance in tough industrial settings.
Alloy Steel Grade 5 Coil typically features a well-balanced mix of carbon, manganese, chromium, molybdenum, and silicon, which enhances its strength and toughness. This alloy is known for its excellent wear resistance, high tensile strength, and good hardenability. It can handle moderate to high temperatures while keeping its structural stability and fatigue resistance intact. Thanks to its blend of ductility and strength, Alloy Steel Grade 5 Coil can be heat treated to achieve specific mechanical properties, ensuring it performs optimally in demanding industrial and engineering applications. Its uniform microstructure guarantees reliability and longevity, even under heavy-duty use.
| Specifications | : | ASTM A387 / ASME SA387 |
| Thickness | : | 1mm-300mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, 4050mm etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, 12000mm, 15000mm etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| Alloy Steel Gr 5 | 0.15 max | 0.30-0.60 | 0.5 max | 0.035 max | 0.030 max | 4.0 – 6.0 | 0.45 – 0.65 | – | – |
| Tensile (MPa) | Tensile (MPa) | Yield (MPa) | Elongation (50mm) | Elongation (200mm) | Reduction of Area |
|---|---|---|---|---|---|
| ASTM A387 Gr. 5 Cl. 1/2 | 415 – 585 | 205 min | 18% min | – | 40% min |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
You’ll find Alloy Steel Grade 5 Coil in a variety of applications, including automotive components, heavy machinery, structural frameworks, and industrial equipment. Its impressive strength and toughness make it perfect for manufacturing shafts, gears, bolts, and high-pressure pipelines. In construction, it’s used for load-bearing structures and reinforcements. Plus, this steel is essential for making tools, dies, and wear-resistant parts where durability is key. Its resistance to fatigue and wear ensures safety and longevity, making it a go-to choice for industries that need consistent performance in extreme conditions, including oil and gas.
Â
Alloy Steel Grade 5 Coil is extensively used in high-strength, wear-resistant, and durable applications. It is generally applied in the production of automotive parts, industrial equipment, and heavy machinery because of its superior toughness and fatigue life. It is also employed in construction for structural components, pipes, and pressure vessels, where it must resist high temperatures and pressures. This coil is also preferred in defense and aerospace industries for essential components.
