Phanuphong Steel and Plates, a reputable manufacturer and supplier located in Bangkok, Thailand, specializes in high-quality Alloy Steel Gr B7M Fasteners that are crafted to meet the rigorous demands of various industries. Renowned for their precision, durability, and outstanding performance, these fasteners are produced using cutting-edge techniques and top-notch materials. With a strong commitment to international standards, Phanuphong Steel guarantees that its B7M fasteners provide exceptional tensile strength, corrosion resistance, and reliability. Serving the oil, gas, petrochemical, and construction sectors, the company offers fasteners that ensure safety, efficiency, and long-lasting performance even in tough conditions.
Alloy Steel Gr B7M Fasteners are primarily made from chromium and molybdenum, which give them remarkable hardness and toughness. They contain controlled amounts of carbon, manganese, and silicon, which enhance their mechanical properties. These fasteners are tempered to lower hardness levels compared to standard B7 grade, making them ideal for applications where hydrogen embrittlement is a concern. Mechanically, they boast high tensile strength, excellent yield strength, and dependable elongation characteristics. Their balanced hardness ensures durability, resistance to stress, and a long service life, making them reliable for high-pressure and high-temperature environments.
Specification :Â ASTM A 193 ASME SA 193
Standard :Â DIN, ASTM, BS and all International Standards
Length :Â 3 mm to B7M mm
Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes
Types :Â Nuts, Bolts, Screws, Sockets, Studs, Screw, Hex Set Screw, Socket Screw, Cap Screw, Pan Head Screw, Socket Head Cap Screw, Washers, Spring Washers, Studs, Anchors
| Alloy Steel B7M | C | Mn | P | S | Si | Cr | Mo |
| 0.37-0.49 | 0.65-1.10 | 0.035 Max | 0.04 Max | 0.15-0.35 | 0.75-1.20 | 0.15-0.25 |
| Grade | Size | Tensile ksi, min | Yield, ksi, min | Elong, %, min | RA % min |
|---|---|---|---|---|---|
| B7M | Up to 2-1/2 | 125 | 105 | 16 | 50 |
| 2-5/8 – 4 | 115 | 95 | 16 | 50 | |
| 4-1/8 – 7 | 100 | 75 | 18 | 50 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
|
Hexagon Bolts / Set Screws |
Stud Bolts |
Hexagon Nuts |
Socket Capscrews |
|---|---|---|---|
|
DIN 931 |
BS4882 |
DIN 934 |
DIN 912 |
|
DIN 933 |
DIN 976 |
BS 1768 |
DIN 6912 |
|
BS 1768 |
BS 1769 |
DIN 7984 |
|
|
UNI 5731 |
BS 1083 |
ANSI B18.3 |
|
|
UNI 5739 |
BS 3692 |
ISO 4762 |
|
|
ISO 4014 |
ISO 4032 |
UNI 5931 |
|
|
ISO 4017 |
ISO 4033 |
BS 2470 |
|
|
BS 1769 |
ANSI B18.2.2 |
BS 4168 |
|
|
BS 3692 |
|||
|
ANSI B18.2.1 |
|||
|
Socket & Slotted Set Screws |
Socket & Slotted Countersunk Screws |
Studs |
Washers |
|
DIN 913 |
DIN 963 |
DIN 938 |
DIN 125 |
|
DIN 914 |
DIN 7991 |
DIN 939 |
DIN 9021 |
|
DIN 915 |
BS 4168 |
DIN 2510 |
BS 4320 |
|
DIN 916 |
BS 1981 |
BS 4439 |
BS 3410 |
|
DIN 551 |
BS 483 |
BS 2693 |
|
|
DIN 553 |
BS 2470 |
Spring Washers |
|
|
DIN 438 |
DIN 127 |
||
|
BS 4168 |
BS 4464 |
||
|
BS 1802 |
Alloy Steel Gr B7M Fasteners are widely utilized in industries that require high strength and exceptional reliability in challenging conditions. They find extensive use in oil and gas refineries, chemical plants, and petrochemical sectors, where resistance to stress corrosion cracking is vital. In power generation and marine applications, these fasteners provide durability under extreme pressure and temperature. They are also employed in pipelines, heat exchangers, and construction projects to ensure secure joints and structural integrity. Their performance in harsh environments makes them a trusted choice for critical applications that demand longevity and reliability.
Phanuphong Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Bangkok, Thailand.
