Phanuphong Steel and Plates, a top-notch manufacturer and supplier located in Bangkok, Thailand, is all about providing high-quality Alloy Steel F12 Flanges tailored to meet the diverse needs of various industries. These flanges are celebrated for their strength, durability, and precision engineering, making them perfect for high-temperature and high-pressure applications. With state-of-the-art manufacturing facilities and rigorous quality control measures, Phanuphong Steel guarantees reliability and adherence to international standards. Customers around the globe trust our Alloy Steel F12 Flanges for their outstanding performance, resistance to corrosion, and cost-effectiveness, which makes them a go-to choice in the oil, gas, power, and chemical processing sectors.
Alloy Steel F12 Flanges are primarily made up of chromium, molybdenum, and other key alloying elements that boost their mechanical and chemical properties. They deliver impressive tensile strength, excellent yield strength, and good elongation, making them ideal for tough conditions. Molybdenum enhances hardness and high-temperature resistance, while chromium improves oxidation resistance. These flanges are tough, ductile, and durable, making them a reliable option for high-pressure and thermal applications in critical process industries worldwide.
Alloy Steel Flanges Specification : ASTM A182 / ASME SA182
Dimension Standard : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Size : 1/2″ (15 NB) to 48″ (1200NB)
Class / Pressure : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
DIN Flanges : DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673.
JIS Flanges : JIS B2220 5K, JIS B2220 10K, JIS B2220 16K, JIS B2220 20K
BS Flanges : BS4504 PN 6, BS 4504 PN 10, BS4504 PN 16, BS4504 PN 25, BS4504 PN 40, BS 4504 PN 64, BS 4504 PN 100, BS 4504 PN 160, BS 4504 PN 250, BS 10, BS Table D, BS Table E, BS Table F, BS Table H.
| Grade | C | Mn | P | S | Si | Ni | Ch | Mo | Cb |
|---|---|---|---|---|---|---|---|---|---|
| F12 | 0.05-0.15 | 0.30-0.60 | 0.045 | 0.045 | 0.50 max | – | 0.80-1.25 | 0.44-0.65 | – |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| F12 | 415 | 220 | 20 | – | 121-174 |
| STANDARD | UNS | WERKSTOFF NR. |
|---|---|---|
| Alloy Steel F12 | K11562/K11564 | 1.7335 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| SORF (Slip On) | NPS (Nominal Pipe Size) | WRNR (Weld Neck) | NPT (Threaded) | Loose (Lap Joint) | SWRF (Socket Weld) | BLRF (Blind) |
|---|---|---|---|---|---|---|
| 1 | ½ | 2 | 1 | 1 | 2 | 2 |
| 2 | ¾ | 2 | 2 | 2 | 2 | 2 |
| 2 | 1 | 3 | 2 | 2 | 2 | 2 |
| 3 | 1¼ | 3 | 3 | 3 | 3 | 3 |
| 3 | 1½ | 4 | 3 | 3 | 3 | 4 |
| 5 | 2 | 6 | 5 | 5 | 5 | 5 |
| 8 | 2½ | 10 | 8 | 8 | 8 | 7 |
| 9 | 3 | 11.5 | 9 | 9 | 9 | 9 |
| 11 | 3½ | 12 | 12 | 11 | 11 | 13 |
| 13 | 4 | 16.5 | 13 | 13 | 13 | 17 |
| 15 | 5 | 21 | 15 | 15 | 15 | 20 |
| 19 | 6 | 26 | 19 | 19 | 19 | 27 |
| 30 | 8 | 42 | 30 | 30 | 30 | 47 |
| 43 | 10 | 54 | 43 | 43 | 43 | 70 |
| 64 | 12 | 88 | 64 | 64 | 64 | 123 |
| 90 | 14 | 114 | 90 | 105 | 90 | 140 |
| 106 | 16 | 140 | 98 | 140 | 98 | 180 |
| 130 | 18 | 165 | 130 | 160 | 130 | 220 |
| 165 | 20 | 197 | 165 | 195 | 165 | 285 |
| 185 | 22 | 225 | 185 | 245 | 185 | 355 |
| 220 | 24 | 268 | 220 | 275 | 220 | 430 |
Phanuphong Steel is a top manufacturer and supplier of high-quality Alloy Steel F12 Flanges products in Bangkok, Thailand. Specializing in steel solutions, we provide a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel. Our offerings include Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Known for our reliable delivery and superior customer service, we are committed to offering top-tier steel materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your steel needs.
You’ll find Alloy Steel F12 Flanges widely used in industries that demand strong piping connections and dependable sealing solutions under extreme conditions. They’re commonly found in oil refineries, power generation plants, chemical processing facilities, petrochemical industries, and heat exchangers, where resistance to high temperatures and pressures is crucial. Their corrosion and oxidation resistance make them perfect for steam systems, boilers, and turbine pipelines. Plus, their strength and toughness ensure they last long, minimizing maintenance needs and promoting efficient operation in both onshore and offshore applications around the world.
