Phanuphong Steel and Plates, a reputable manufacturer and supplier based in Bangkok, Thailand, specializes in high-quality Carbon Steel EN 10084 Grade 16MnCr5 Pipes. These pipes are expertly crafted to meet the rigorous demands of various industrial, automotive, and mechanical applications. Known for their precision, durability, and compliance with international standards, Phanuphong Steel guarantees that each 16MnCr5 pipe delivers outstanding performance even in high-stress and challenging environments. Catering to clients throughout Thailand and beyond, the company provides corrosion-resistant, high-strength pipes that are perfect for power transmission, machinery, and structural systems. With state-of-the-art production facilities and stringent quality control measures, Phanuphong Steel and Plates stands out as a dependable source for Carbon Steel EN 10084 Grade 16MnCr5 Pipes.
These Carbon Steel EN 10084 Grade 16MnCr5 Pipes are made from medium-carbon alloy steel, containing around 0.15–0.20% carbon, 1.0–1.3% manganese, along with trace amounts of chromium and other elements. In terms of mechanical properties, these pipes boast a tensile strength ranging from 600 to 850 MPa, a yield strength of 350 to 600 MPa, and a Brinell hardness of 180 to 230 HB. They are designed to offer excellent wear resistance, toughness, and fatigue strength. The unique combination of their chemical makeup and heat treatment capabilities ensures high machinability, impressive surface hardness, and long-lasting performance, making 16MnCr5 pipes perfect for demanding engineering and industrial tasks.
| Standard | AISI, DIN, EN, GB, IS, JIS, ASTM, ASME Pipe |
|---|---|
| Bs EN 10084 Grade C10R Welded Pipe Size | 5.0 mm – 1219.2 mm |
| DIN En 10084 C16e Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| DIN EN 10084 Grade C16E EFW Pipe size | 5.0 mm – 1219.2 mm |
| Norme En 10084 C15e Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| EN 10084 Grade 16MnCr5 Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| EN 10084 Grade C16R Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Norme En 10084 C15e Welded Tube Size | 6.35 mm OD To 152 mm OD |
| En 10084 Steel Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| En 10084 C10e Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| DIN En 10084 C16e Marking | All EN 10084 Material are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Uni En Iso 10084 Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Manufacturers of EN 10084 Grade C16E Pipe |
|
| EN 10084 Grade C16R Carbon Steel Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| EN 10084 Grade 16MnCr5 Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| Bs EN 10084 Grade C10R Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| EN 10084 Grade C16E Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| DIN En 10084 C15e – 1.1141 End | Plain End, Beveled End, Treaded Pipe & Tube |
| Material Test Certificates (MTC) | Material Test Certificates (MTC) as per EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2, 100% Radiography Test Report, Raw Materials Certificate, Third Party Inspection Report, Fumigation Certificates, Heat Treatment Charts, EN 10084 Grade 16MnCr5 Pipe HS Code Commercial Invoice, Form A for Generalized System of Preferences (GSP) |
| EN 10084 Grade C10R Carbon Steel Specialize in |
|
| DIN EN 10084 Grade C16E Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Chemical Properties | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
| 0.14-0.19 | max 0.40 | 1.00-1.30 | 0.035 | 0.035 | – | – | 0.80-1.10 | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Phanuphong Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10084 Grade 16MnCr5 Pipe products in Bangkok, Thailand. Specializing in premium steel materials, we offer a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a commitment to reliable delivery and exceptional customer service, Phanuphong Steel ensures top-grade materials for superior performance across various industrial applications. Trust Phanuphong Steel for all your Carbon Steel EN 10084 Pipe needs.
Carbon Steel EN 10084 Grade 16MnCr5 Pipes find extensive use in industries that require robust, wear-resistant, and durable piping solutions. They are particularly well-suited for automotive components like shafts, gears, and axles, as well as in power transmission systems. In mechanical and engineering contexts, these pipes are utilized in industrial machinery, spindles, and structural frameworks. Their ability to be carburized, hardened, and machined makes them ideal for high-performance applications where precision is critical. Carbon Steel EN 10084 Grade 16MnCr5 Pipes ensure reliable, long-lasting performance in a variety of demanding settings.
